Hot Dip Galvanized 3D Panel Fence

Hot Dip Galvanized 3D Panel Fence

3D curved fence,Appropriate bending of wire mesh fence, creates the unique aesthetic effect of this product, and the surface is treated with a variety of colors, such as yellow, green, and red. The combination of different colors of the column and the mesh is even more pleasing.
Send Inquiry
Description
Technical Parameters

Product Introduction

A 3D panel fence is a welded wire panel with 2–4 horizontal V-shaped ribs pressed into the mesh. These ribs are not decoration - each bend acts like a stiffener, so a 2.5 m wide panel stays rigid without a heavy frame. After welding, panels go through hot-dip galvanizing, which bonds a zinc layer to every weld point and wire intersection - exactly where rust starts on cheap spray-painted panels. The result is a fence line that stays straight and rust-free for years with almost no maintenance.

product-750-750

Technical Specifications

Panel heights

0.63 / 0.83 / 1.03 / 1.23 / 1.53 / 1.83 / 2.03 / 2.43 m

Panel length

2.0 / 2.5 / 3.0 m

Mesh size

50 × 150 mm · 50 × 200 mm

Wire diameter

3.0–4.0 mm before coating · 3.85–5.0 mm after PVC

Horizontal ribs

2 ribs under 1.23 m · 3–4 ribs above 1.53 m

Coating

Hot-dip galvanized ≥70 µm · optional PVC in green, yellow, red

Posts & fittings

Flanged posts + expansion bolts, or bury-in posts; clamps and gates optional

product-1000-604

Product Details



product-1000-838



Product Application



product-1000-1507





Galvanized or Galvanized + PVC?

Bare hot-dip galvanized - the economical choice for dry inland sites, factories and warehouses; silver finish weathers to a uniform grey.

Galvanized + PVC coated - the zinc layer protects the steel, the PVC layer protects the zinc; best for coastal areas, schools and residential projects where green RAL 6005 is the standard color.

Typical Applications

Hot-dip galvanized 3D panel fencing is widely used for factory perimeters, schools and playgrounds, residential communities, airports, sports fields and storage yards. Compared with chain link or welded roll fencing, rigid 3D panels keep a straight, architectural look over uneven ground, and the flanged-post system lets two workers install 100+ meters per day with just anchor bolts - no welding or concrete waiting time on flat surfaces.

FAQ

Q: Do you supply a complete system or only panels?
Complete: panels, posts, clamps, bolts, gates and optional razor or barbed wire toppers - one shipment, one project, no missing parts on site.

Q: What is the MOQ and lead time?
MOQ is one 20ft container (approx. 200 panels mixed heights); stock specs ship in 10–15 days after galvanizing.

Q: Can panels match a drawing or tender specification?
Yes. Send your tender document or drawing - we adjust mesh, wire and height to spec and provide mill test certificates and zinc coating thickness reports.

Q: How are panels packed?
Stacked flat on steel pallets with plastic film - one 40ft container loads approx. 500 panels, ready for direct jobsite unloading.
